Compact 360° microwave motion sensor detects movement up to 7 metres using 5.8 GHz radar to minimise unnecessary lighting and save energy. Adjustable time delay (8 s–12 min), sensitivity (1–8 m) and lux threshold (2–2000 lx) let you fine‑tune performance for corridors, stairs and garages. Ceiling-mount design with simple L/N connections supports up to 1200 W load for bulbs and fixtures. Durable plastic body, easy install and 18 months manufacturer warranty make it a fuss‑free automation upgrade.

Model	QS-M3
Detection Technology	Microwave (5.8 GHz CW radar, ISM band)
Detection Angle	360°
Detection Range	Up to 7 metres (radius)
Time Delay	Adjustable 8 seconds to 12 minutes
Sensitivity	Adjustable 1–8 metres
Lux (Light) Setting	Adjustable 2–2000 lux
Rated Load	1200 W (suitable for incandescent, LED drivers depending on driver compatibility)
Mounting Type	Ceiling mount
Power / Connections	Corded electric; Connection points: L (Live), N (Neutral), L' (Load)
Material / Finish	Durable white plastic housing
Product Dimensions	Approx. 5.5 × 4.0 × 2.5 cm (length × width × height)
Item Weight	0.10 kg
Operating Environment	Indoor use; adjustable for day/night via lux control
Warranty	18 months manufacturer warranty
Country of Origin	India
